Introducing The KRATOS™ Wall

STEEL FRAMING WITHOUT THERMAL BRIDGING

The KRATOS™ Wall System is a 4-in-1 exterior wall solution that is revolutionizing the construction industry as a lighter, stronger more durable and energy efficient alternative to traditional block/wood structures.

4-in-1 Features Built-in

  • Structural Framing - Galvanized light gauge steel with prepunched service holes for electric & plumbing trades.
  • Insulation - Closed cell spray foam & rigid exterior sheathing with impact rated mesh layers provide R-16+ from factory.
  • Impermeability - Closed cell spray foam & exterior sheathing provide a complete moisture/air barrier (WRB).
  • Exterior Sheathing - Impact rated continuous insulative sheathing provides thermal break and is ready for cladding. MX7 series provides additional structural integrity, fire/impact protection, nail/screw surface and a reduced carbon footprint.

KEY

  1. Direct Applied Exterior Cladding
  2. Exterior sheathing layer (X4 or MX7 options)
  3. Closed cell spray foam insulation
  4. Light gauge steel framing w/ service holes
  5. Interior gypsum / MGO sheathing

Key Features & Benefits

  • Integrated Value-Engineered Building Solution - Single Source
  • Lab Tested for Impact, Wind Load & Moisture/Air Penetration
  • Meets IBC/Florida/Other Building Code Requirements
  • Patented Layered Technology provides thermal break
  • Continuous Insulation & built-In WRB - No need to wrap building
  • MX7 product line provides negative carbon sheathing w/nail surface
  • Green Energy Efficient - 50% to 80% Savings

Environmental & financial sustainability

  • Highest strength-to-weight ratio with no weak spots
  • Healthy - No dry-rot, termites, moisture, mold or mildew
  • Long-term Durability & Consistent Performance
  • Absorbs seismic/storm energy, bends without breaking
  • Green Energy Efficient - 50% to 80% Savings
  • Low to no waste technology facilitates low Carbon Footprint
  • Trade-Friendly with pre-punched service holes
  • Lowest cost of ownership (TCO)
  • Made in the USA with highest grade G60/G90 steel
  • Fast & easy to install - Rapid tilt-wall process with smaller crew
  • Lightweight wall panels & trusses reduce heavy equipment needs
  • Reduced waste, labor, inspections, build time
  • Environmental & financial sustainability
  • Positive consistent load path - dimensionally stable
  • Provides excellent fire protection, is non-combustible
  • Recycled & recyclable - low carbon footprint

Product Matrix

KRATOS™ X4 Exterior Wall System

  • Product ID: X4
  • Stud Configuration: Single 5.5 LGS @ 24 O.C. Max
  • CFS Spec:

Standard:

Optional:

20 GA, 50 KSI
18 GA, 50KSI

20 GA, 50 KSI
18 GA, 50KSI

  • Corrosion Protection:
  • Sheathing: 1" HD KRATOS™ EPS
  • Insulation: Pre-insulated, rated @ R-18
  • Use: Curtain Structural
  • HVHZ Design Pressure: +/- 45
  • HVHZ Impact Rated: Yes
  • Weight (Lbs/SF): 4.50 - 20ga, 4.90 - 18ga

Standard:

Optional:

HDG G90

HDG G60

KRATOS™ X4+ Exterior Wall System

  • Product ID: X4+
  • Stud Configuration: Single 5.5 LGS @ 24 O.C. Max
  • CFS Spec:

Standard:

Optional:

20 GA, 50 KSI
18 GA, 50KSI

16 GA, 50 KSI
16 GA, 70KSI

  • Corrosion Protection:
  • Sheathing: 1" HD KRATOS™ EPS
  • Insulation: Pre-insulated, rated @ R-18
  • Use: Curtain Structural
  • HVHZ Design Pressure: +/- 127.5
  • HVHZ Impact Rated: Yes
  • Weight (Lbs/SF): 2.17 - 20ga, 2.70 - 18ga

Standard:

Optional:

HDG G90

HDG G60

KRATOS™ MX7 Exterior Wall System

  • Product ID: MX7
  • Stud Configuration: Single 5.5 LGS @ 24 O.C. Max.
  • CFS Spec:

Standard:

Optional:

20 GA, 50 KSI
18 GA, 50KSI

16 GA, 50 KSI
16 GA, 70KSI

  • Corrosion Protection:
  • Sheathing: 1" HD KRATOS™ MGO/EPS
  • Insulation: Pre-insulated, rated @ R-16
  • Use: Curtain Structural
  • HVHZ Design Pressure: +/- 70
  • HVHZ Impact Rated: Yes
  • Weight (Lbs/SF): 4.50 - 20ga, 4.90 - 18ga

Standard:

Optional:

HDG G90

HDG G60

KRATOS™ MX7+ Exterior Wall System

  • Product ID: MX7+
  • Stud Configuration: Double 5.5 LGS @ 24 O.C. Max.
  • CFS Spec:

Standard:

Optional:

20 GA, 50 KSI
18 GA, 50KSI

16 GA, 50 KSI
16 GA, 70KSI

  • Corrosion Protection:
  • Sheathing: 1" HD KRATOS™ MGO/EPS
  • Insulation: Pre-insulated, rated @ R-16
  • Use: Curtain Structural
  • HVHZ Design Pressure: +/- 150
  • HVHZ Impact Rated: Yes
  • Weight (Lbs/SF): 4.87 - 20ga, 5.40 - 18ga

Standard:

Optional:

HDG G90

HDG G60
